Power Amplifier：PA4501A
| 所屬分類: | RF Products |
|---|
詳細介紹
Specification
| Frequency Range | 20MHz – 1000MHz |
| Gain | 45dB (typical) |
| Flatness | +/- 2dB |
| P1dB Output Power | +37dBm (typical) |
| Maximum Input | -8dBm (Recommed) -5dBm (Damage) |
| Input VSWR | 1.9:1 (typical) |
| Output VSWR | 2.6:1 (typical) |
| AC Input | 100 – 240V |
| Supply Power | 80W |
